Superior Durability That Looks Good Too
Achieve the sleek, high-end appearance of standing seam metal roofing—without exposed screws—using Horizon-Loc (H-Loc®). This advanced snap-lock panel system delivers the clean lines and weather performance of traditional standing seam roofing at a lower overall cost.
H-Loc® panels feature concealed fasteners and a snap-together design, eliminating the need for mechanical seaming. This speeds up installation, simplifies labor, and can significantly reduce installation costs compared to conventional standing seam systems.
Our metal roofing and metal siding panels are:
-
Fire-resistant
-
Superior wind rating
-
Engineered for long-term durability
-
Available in multiple profiles and colors
To further protect your investment, we offer CentralGuard®, a premium coating system designed to safeguard both metal roofs and exterior metal cladding against corrosion, fading, and environmental wear.
At K&R Metal LLC, you can price and order Horizon-Loc standing seam metal roofing directly, backed by fast turnaround and materials built for decades of performance.

APPLICATION: Roofing, Siding, Buildings
FASTENER SYSTEM: Hidden
ROOF PITCH (minimum): 3:12
GAUGE: 26 gauge (24 gauge available in Texas)
PANEL COVERAGE WIDTH: 16″
RIB HEIGHT: 1″
DISTANCE FROM RIB-TO-RIB: 16″
STEEL THICKNESS: 0.0185″
PAINT THICKNESS
-
Top coat paint: .70 mil
-
Top coat primer: .30 mil
-
Bottom coat backer: .35 mil
-
Bottom coat primer: .35 mil
TOTAL THICKNESS: 0.0202″
RUST PROTECTANT SUBSTRATE: Galvalume AZ50 or AZ55 acrylic-coated
STEEL STRENGTH: 50,000 PSI min
PAINT SYSTEM: SMP and Fluropon selections available
TEXTURED COLORS AVAILABLE: Yes
WARRANTY
-
Lifetime limited paint adhesion
-
30-yr. chalk and fade
-
50-yr. Galvalume perforation
